European Standard 1500V Liquid-Cooled Charging Cable (HPC – High Power Charging)
The 1500V Liquid-Cooled Charging Cable is a high-performance solution specifically designed for ultra-fast electric vehicle (EV) charging systems. Utilizing advanced liquid cooling technology, the cable supports continuous high current transmission (up to 500A/600A), minimizing heat generation and enabling safe, efficient charging for next-generation electric vehicles.
Built to meet IEC 61851 and IEC 62196-3 (CCS2) European standards, this cable is engineered with low-resistance tinned copper conductors, temperature sensors, and coolant channels, providing optimal heat dissipation and long service life even under extreme environmental conditions.
High Voltage Support: Rated up to 1500V DC, suitable for new-generation EV platforms and HPC charging stations.
Liquid Cooling System: Internal coolant circulation effectively manages cable temperature, enabling stable transmission of 500A–600A current.
Fully Compliant: Built to IEC 61851, IEC 62196-3 (Combo 2), EN standards, and TÜV/CE/RoHS certifications.
Enhanced Durability: UV-resistant, flame-retardant, oil-resistant outer sheath; designed for prolonged outdoor use.
⚡ Low Power Loss: Stranded copper conductors with low resistance to maximize charging efficiency.
Custom Configurable: Available in different conductor sizes, sheath colors, and connector types based on customer request.
| Parameter | Value |
|---|---|
| Rated Voltage | DC 1500V |
| Rated Current | 500A / 600A (liquid cooled) |
| Conductor Material | Tinned copper (Class 5, flexible) |
| Insulation | XLPE / TPU / LSZH |
| Outer Sheath | Thermoplastic polyurethane (TPU) |
| Operating Temperature | -40°C to +90°C |
| Standards | IEC 61851, IEC 62196-3 (CCS2), EN |
| Certifications | TUV, CE, RoHS |
| Cooling Type | Internal liquid coolant circulation |
| Sensor | Optional built-in temperature sensor |
High Power EV Charging Stations (urban and highway)
Public & Commercial Charging Infrastructure
Electric Bus & Heavy Vehicle Charging Yards
Fleet Charging Depots
Fast Charging Networks across Europe, Africa, Middle East, Central Asia
Cable length (1.5m – 15m)
Connector types: CCS2, CHAdeMO (on request)
Color coding & logo printing
Anti-theft lockable head / temperature sensor integrated design
